Rain Bird R-VAN Adjustable Rotary Nozzles are high efficiency multi stream sprinkler nozzles designed to provide superior water distribution, reduced runoff, and improved performance compared to traditional fixed spray nozzles such as Toro 570 series. The rotating stream technology delivers larger droplets that resist wind distortion while maintaining matched precipitation across different arcs and radii. These nozzles are easy to adjust by hand without tools and are compatible with all standard Rain Bird spray bodies, risers, and adapters, making them an ideal upgrade for residential and commercial irrigation systems.

SPECIFICATIONS

• Arc adjustment range: 45° to 270° adjustable models and 360° full circle models

• Radius options: 2.4m to 7.3m depending on model (8ft to 24ft coverage)

• Pressure range: 30 to 55 psi (2.1 to 3.8 bar)

• Recommended operating pressure: 45 psi (3.1 bar)

• Spacing: 2.4m to 7.3m depending on model and layout

• Trajectory angle: Variable multi stream trajectory from approximately 4° to 34°

• Construction: UV resistant plastic body with stainless steel protective cap

• Filter: Removable mesh filter screen to prevent clogging

• Compatibility: Fits Rain Bird spray bodies and standard threaded risers

• Warranty: 3 years

Commonly paired with Rain Bird Pop Up Body, Compatible with all models of Rain Bird spray bodies, risers and adapters.

Product Specification

Rain Bird Rotary Nozzles Specs

Features:

• Adjustable Arc from 25°-270°, or Fixed Arc 360°
• Precipitation is matched across the radius, arc and pattern types
• The low precipitation rate reduces erosion
• Both the radii and arcs can be adjusted without the use of tools
• There is a pull-up to flush feature that clears the nozzle of dirt and debris
• Provides and maintains optimal efficient performance at high operating pressures without misting and or fogging

Rain Bird Matched Precipitation Rate (MPR) nozzles are designed to simplify irrigation system design by allowing sprinklers with different arcs and radii to operate efficiently on the same watering zone. These precision-engineered spray nozzles deliver consistent water distribution, improved uniformity, and reliable performance across residential and commercial irrigation systems.

Compatible with all Rain Bird spray heads and shrub adapters, MPR nozzles feature durable construction, colour-coded identification, and stainless steel radius adjustment for accurate coverage control. Integrated filter screens help prevent clogging and maintain long-term performance, making them ideal for lawns, gardens, and landscaped areas requiring dependable irrigation.

SPECIFICATIONS

• Spacing: 1.5m to 4.5m

• Operating Pressure: 1.0 to 2.1 bar (15 to 30 psi)

• Optimum Pressure: 2.1 bar (30 psi)

• Available Radius Options: 5 ft, 8 ft, 10 ft, 12 ft, 15 ft

• Available Arc Options: Full, Half, Quarter, Strip Patterns

• Trajectory Options: Multiple depending on model

• Adjustment: Stainless steel radius adjustment screw

• Compatibility: Fits Rain Bird spray heads and shrub adapters

• Filter Screens: Fine mesh screens included depending on series

Commonly paired with Rain Bird Pop Up Body

Product Specification

Sprinklers Brass Impact Coupling 15mm FI

Plastic Impact

Plastic impact sprinklers are an economical way of watering large gardens or planted areas, they are also suitable for medium sized gardens as well as overhead watering systems such as those used in nurseries. Impact sprinklers feature a long spray radius and a uniform water distribution allowing it to simulate the effect of rainfall.

A - Product Specification

B - Product Specification

C - Product Specification

D - Product Specification

Netafim SuperNet Sprinkler 63500-120470
40 Litres per hour, 1.8 metre wetted diameter, working pressure range 150 kpa to 400kpa

Features:

• Sprinkler on stake. Includes 60 centimetres of micro tube.
  SRD (Short Range with Deflector) sprinklers come equipped with a deflector concentrating the spray in a shorter range (suiting young trees). This deflector can be snapped off to extend the range of the sprinkler (better suiting larger, older trees).
  Sprinkler on stake. Includes 60 centimetres of micro tube.
• SRD (Short Range with Deflector) sprinklers come equipped with a deflector concentrating the spray in a shorter range (suiting young trees). This deflector can be snapped off to extend the range of the sprinkler (better suiting larger, older trees).
• Pressure compensated. Provides consistent flow within a broad pressure range (150 kpa to 400 kpa).
• Wide channels minimise clogging (30% wider than industry standard).
• Anti-ant mechanisms prevent insect penetration in the micro sprinkler nozzle.
• Supernet sprinklers are designed with materials resistant to agrochemicals and weather conditions.

Applications:

• Under tree irrigation.
• Orchards (cooling).

Product Specifications and Full Range
Contact us to special order other products in this range.

Sprinklers Orbit Pop - Up Body 2' With 18A Nozzle 15mm

Stainless steel 316 male x female reducing bushes are used to adapt threaded fittings, valves, manifolds and pipework from one size down to another. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant threaded reducing connection is required.

Made from grade 316 stainless steel, these reducing bushes provide a male BSP outside thread with a smaller female BSP internal thread. Use suitable thread sealant or PTFE tape when installing into compatible BSP threaded fittings.

Stainless Steel 316 Reducing Bush Male x Female BSP Specifications

Stainless steel 316 male threaded hex plugs are used to blank off female BSP threaded fittings, outlets and pipework. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant threaded plug is required.

Made from grade 316 stainless steel, these hex plugs provide a male BSP thread with a hex head for installation. Use suitable thread sealant or PTFE tape when installing into female BSP threads.

Stainless Steel 316 Hex Plug Male BSP Specifications

Stainless steel 316 female threaded tees are used to create a branch connection from BSP threaded pipework, fittings and valve assemblies. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant three-way threaded connection is required.

Made from grade 316 stainless steel, these tees provide female BSP threaded connections on all three outlets. Use suitable thread sealant or PTFE tape when installing male BSP threads into the tee.

Stainless Steel 316 Hex Tee Female BSP Specifications

Stainless steel 316 female threaded couplings are used to connect two male BSP threaded fittings, pipe ends or threaded components. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant straight threaded join is required.

Made from grade 316 stainless steel, these couplings provide female BSP threaded connections at both ends. Use suitable thread sealant or PTFE tape when installing male BSP threads into the coupling.

Stainless Steel 316 Coupling Female BSP Specifications

Stainless steel 316 female threaded 90° elbows are used to change the direction of BSP threaded pipework, fittings and valve connections. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant right-angle threaded connection is required.

Made from grade 316 stainless steel, these 90° elbows provide female BSP threaded connections at both ends. Use suitable thread sealant or PTFE tape when installing male BSP threads into the elbow.

Stainless Steel 316 Elbow 90° Female BSP Specifications

Flush Head Sprinklers

Stainless Steel Flush Head Conical Spray Sprinkler

Stainless Steel Body, 360 degree conical spray from top
5m Diameter (2.5m Radius), operating pressure 200kPa
Product Specification

Stainless steel 316 male x male threaded reducing hex nipples are used to adapt between two different female BSP threaded fittings, valves or pipe connections. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant straight threaded connection needs to change size.

Made from grade 316 stainless steel, these reducing hex nipples provide male BSP threaded connections at both ends in different sizes, with a hex centre for installation. Use suitable thread sealant or PTFE tape when installing into female BSP threads.

Stainless Steel 316 Reducing Hex Nipple Male x Male BSP Specifications

Stainless steel 316 male x male threaded hex nipples are used to connect two female BSP threaded fittings, valves or pipe connections. They are suitable for marine, pumping, commercial, domestic chemical, irrigation and general water applications where a corrosion-resistant straight threaded join is required.

Made from grade 316 stainless steel, these hex nipples provide male BSP threaded connections at both ends with a hex centre for installation. Use suitable thread sealant or PTFE tape when installing into female BSP threads.

Stainless Steel 316 Hex Nipple Male x Male BSP Specifications

316 grade stainless steel wire rope and wire rope grips are used for balustrade, shade structures, architectural rigging, green walls, cable trellis, marine-style and general purpose applications. This range includes 7 x 7 stainless steel wire rope in selected 3.2mm and 4.0mm sizes, along with matching stainless steel wire rope grips for securing compatible wire rope.

The 7 x 7 wire rope has a semi-flexible construction with a bright braided finish, making it suitable for use around compatible thimbles, fittings and hand swaged sleeves. Stainless steel wire rope grips provide a mechanical fastening option where the grip size is matched to the wire rope diameter. Select wire rope, grips and fittings to suit the application, load requirements and installation method.

PVC Stormwater Level Invert

Commonly used for sewer and vent applications

Complies with AS/NZS 1260
