Stormwater Threaded Coupling 90 mm
Stormwater Threaded Coupling 90 mm

STORMWATER THREADED COUPLING 90MM

Stormwater Threaded Coupling 90mm joins two sections of 90mm stormwater pipe and provides a male external thread for a removable access cap.

✓ Two 90mm Sockets Fit Over Approximately 90mm OD Pipe
✓ External Male Thread Accepts a Matching Access Cap
✓ Solvent-Weld Pipe Joints with Removable Cap Access
✓ Suitable for Non-Pressure Stormwater Systems

Stormwater Pipe Dimensions
Stormwater PVC Jointing & Installation Guide

More Information
Product Specifications
Stormwater Threaded Coupling 90 mm
STORMWATER THREADED COUPLING 90MM
Stormwater Plain Coupling 75 mm
Stormwater Plain Coupling 75 mm SW02C075
$4.29 /each
Stormwater Plain Coupling (Slip) 90 mm
Stormwater Plain Coupling (Slip) 90 mm SW02C090
$2.41 /each
Stormwater Threaded Coupling 90 mm
Stormwater Threaded Coupling 90 mm SWCT090
$2.23 /each
Stormwater Plain Coupling 225 mm
Stormwater Plain Coupling 225 mm SW02C225
$46.32 /each
Stormwater Plain Coupling 300 mm
Stormwater Plain Coupling 300 mm SW02C300
$110.64 /each

Stormwater Threaded Coupling 90mm joins two lengths of pipe like a plain coupling. It also has a male external thread around one socket end for a matching threaded access cap.

Both 90mm female sockets fit over pipe with an approximately 90mm outside diameter. The access cap screws onto the external thread and can be unscrewed and refitted when access is required.

The pipe sockets are joined using PVC priming fluid and suitable non-pressure PVC solvent cement. The threaded cap connection remains removable.

Suitable for non-pressure PVC stormwater and surface-water drainage systems.

Stormwater Pipe Dimensions
Stormwater PVC Jointing & Installation Guide

✓ Product Type & Size
PVC Stormwater Threaded Coupling 90mm
(90mm Female Stormwater Socket x 90mm Female Stormwater Socket with Male External Access Thread).

✓ Function & Design
Connects two sections of 90mm PVC stormwater pipe in a straight line while providing a threaded connection for removable access. A male external thread accepts a matching 90mm threaded cap or compatible diverter cap. The cap can be unscrewed and refitted when access to the stormwater pipework is required.

✓ Connections
Both female sockets fit over 90mm PVC stormwater pipe with an approximately 90mm outside diameter.

✓ Joining
The two pipe sockets are joined using PVC priming fluid and suitable non-pressure PVC solvent cement. The threaded cap connection remains removable.

✓ Application
Suitable for non-pressure PVC stormwater drainage systems.
