Hunter Controller ICC2 8 Station Metal Cabinet (Max 54 Stations Conventional, 54 Stations Decoder)

HUNTER ICC2 METAL CABINET CONTROLLER 8–54 STATIONS

Name: Hunter Controller ICC2 8 Station Metal Cabinet (Max 54 Stations Conventional, 54 Stations Decoder)
Brand: Hunter
SKU: CNHICC208M
Price: 1645.15 AUD
Availability: InStock

Irrigation Controllers & Timers

The Hunter ICC2 8 Station Metal Cabinet Controller is built for larger residential, commercial and municipal irrigation systems that need high station capacity in a durable wall-mount cabinet. Additional conventional wired stations can be added using compatible ICM expansion modules, or the controller can be upgraded with an EZ-DM module for Hunter EZ Decoder System two-wire operation. It is a practical choice for larger installations that need a robust modular controller with flow monitoring and room for future system growth.

✓ 8 Station Metal Cabinet Controller
✓ Conventional Wiring: Expands up to 54 Stations
✓ Decoder Wiring: Supports up to 54 Stations with EZ-DM Module
✓ Built-In Flow Monitoring
✓ Optional Centralus™ Connectivity
✓ 5 Year Hunter Warranty

Hunter ICC2 Controller User Manual
Hunter ICC2 Controller Installation Guide
Hunter ICC2 Controller Programming Guide
Hunter ICC2 Controller Specifications
Hunter ICC2 Controller Door Card
Hunter ICC2 Controller EZ-DM Decoder Module Installation Guide
Hunter EZ Decoder System Brochure

More Information

Product Specifications

Product Videos

HUNTER ICC2 METAL CABINET CONTROLLER 8–54 STATIONS

Hunter Controller ICC2 8 Station Plastic Cabinet No Cable (Max 38 Stations Conventional, 54 Stations Decoder) CNHICC208PL

$618.50 /each

$618.50 inc GST

Total: $0

Hunter Controller ICC2 8 Station Plastic Cabinet Corded (Max 38 Stations Conventional, 54 Stations Decoder) CNHICC208PLC

$642.98 /each

$642.98 inc GST

Total: $0

Hunter Controller ICC2 8 Station Metal Cabinet (Max 54 Stations Conventional, 54 Stations Decoder) CNHICC208M

$1,645.15 /each

$1,645.15 inc GST

Total: $0

Hunter Controller HCC Wi-Fi 8 Station Plastic Cabinet No Cable (Max 38 Stations Conventional, 54 Stations Decoder) CNHHCC8PL

$1,039.62 /each

$1,039.62 inc GST

Total: $0

Hunter Controller HCC Wi-Fi 8 Station Plastic Cabinet Corded (Max 38 Stations Conventional, 54 Stations Decoder) CNHHCC08

$1,285.08 /each

$1,285.08 inc GST

Total: $0

Hunter Controller HCC Wi-Fi 8 Station Metal Cabinet (Max 54 Stations Conventional, 54 Stations Decoder) CNHHCC8M

$1,775.58 /each

$1,775.58 inc GST

Total: $0

Hunter ICC2 / HCC 4 Station Expansion Module (ICM-400) CNHICC4EM

$168.05 /each

$168.05 inc GST

Total: $0

Hunter ICC2 / HCC 8 Station Expansion Module (ICM-800) CNHICC8EM

$338.24 /each

$338.24 inc GST

Total: $0

Hunter ICC2 / HCC 22 Station Expansion Module (ICM-2200, One Per Controller) CNHICC22EM

$753.20 /each

$753.20 inc GST

Total: $0

Hunter EZ-DM Decoder Module for ICC2 / HCC (compatible with EZ-1 and EZ-LR) CNHEZDM

$560.27 /each

$560.27 inc GST

Total: $0

Hunter EZ-1 Decoder Single Station (compatible with EZ-DM and PC-DM) CNHEZ01

$159.25 /each

$159.25 inc GST

Total: $0

Hunter EZ-LR Long Range Decoder Single Station (compatible with EZ-DM and PC-DM) CNHEZLR

$9,999 /each

$9,999 inc GST

Total: $0

Hunter ICC2 Retrofit Facepack Kit for Original ICC Controllers (ICCFPUP2) CNHICC2RFP

$525.31 /each

$525.31 inc GST

Total: $0

Hunter HCC-FPUP Hydrawise Wi-Fi Retrofit Upgrade Kit for ICC / ICC2 Controllers (PANEL / MODULE KIT) CNHHCCRFP

$764.21 /each

$764.21 inc GST

Total: $0

The Hunter ICC2 8 Station Metal Cabinet Controller is a high-capacity modular irrigation controller designed for larger residential, commercial and municipal irrigation systems. The metal wall-mount cabinet provides a durable controller option for larger projects and more demanding installation environments.

Supplied as an 8 station base controller, the metal cabinet ICC2 can expand up to 54 conventional wired stations using compatible Hunter ICM station expansion modules. This makes it suitable for larger systems where a high station count is required from a conventional wired controller layout.

For two-wire decoder installations, the ICC2 can also support up to 54 stations when fitted with the Hunter EZ-DM Decoder Output Module and used with compatible EZ-1 or EZ-LR decoders. This provides flexibility for conventional, decoder-based or hybrid irrigation designs.

The ICC2 includes 4 automatic irrigation programs, 8 start times per program, station run times up to 12 hours and the ability to run two programs at the same time. Built-in flow monitoring, dedicated flow and weather sensor inputs, pump/master valve output and optional Centralus™ connectivity provide strong control options for larger irrigation systems.

5 Year Hunter Warranty

✓ Model
Hunter ICC2 8 Station Metal Cabinet Controller.

✓ Station Outputs
8 station base model. The controller also includes a separate P/MV output for a master valve or pump start relay.

✓ Application
Modular irrigation controller suitable for larger residential, commercial and municipal irrigation systems.

✓ Cabinet Type
Metal wall-mount cabinet.

✓ Conventional Wiring Capacity
Expands from 8 to 54 conventional wired stations with compatible Hunter ICM station expansion modules.

✓ Conventional Expansion Modules
Compatible with Hunter ICM-400, ICM-800 and ICM-2200 station expansion modules.

✓ 22 Station Module Limitation
The ICM-2200 22 Station Expansion Module is limited to one per controller.

✓ Decoder Wiring Capacity
Supports up to 54 stations with the compatible Hunter EZ-DM Decoder Output Module.

✓ Decoder Requirements
Decoder stations require compatible Hunter EZ-1 or EZ-LR decoders. Decoders are sold separately.

✓ Wireless Valve Link Option
Supports Wireless Valve Link output up to 54 stations when fitted with compatible Wireless Valve Link components.

✓ Programs
4 automatic irrigation programs for separate watering schedules.

✓ Start Times
8 start times per program.

✓ Station Run Time
Station run times can be set from 1 minute to 12 hours.

✓ Simultaneous Operation
Can operate 2 programs simultaneously.

✓ Watering Schedule Options
Supports 7-day calendar watering, interval watering and odd or even day programming.

✓ Flow Monitoring
Built-in flow monitoring supports smart water management when used with a compatible flow sensor.

✓ Sensor Inputs
2 sensor inputs: 1 weather sensor input for compatible Clik or Solar Sync sensors, and 1 dedicated flow sensor input.

✓ Pump / Master Valve Output
1 P/MV output for pump start relay or master valve activation.

✓ Remote Compatibility
Compatible with Hunter ROAM and ROAM LR remotes.

✓ Centralus™ Connectivity
Optional WIFIKIT, LANKIT or CELLKIT communication modules allow connection to Centralus™ software for web-based central control.

✓ Electrical Output
24VAC transformer output, 1.4A. Station output 24VAC, 0.56A per station. P/MV output 24VAC, 0.56A.

✓ Certifications
Metal wall-mount cabinet rated IP55. RCM approved.

✓ Dimensions
Approximately 406mm high x 330mm wide x 127mm deep.

✓ Warranty
5 Year Hunter Warranty.
