HUNTER CONTROLLER HPC WI-FI MODULAR 4-32 STATIONS

The Hunter HPC Wi-Fi Modular 4 Station Base Controller is a flexible smart irrigation controller with built-in Hydrawise® control. Additional stations can be added using compatible PCM expansion modules, or the controller can be upgraded with a PC-DM module for Hunter EZ Decoder System two-wire operation. It is suited to residential and light commercial installations where app-based control, weather-based scheduling and future expansion are required.

✓ 4 Station Wi-Fi Modular Base Controller
✓ Built-In Hydrawise® Smart Irrigation Control
✓ Conventional Expansion up to 23 Stations with PCM Modules
✓ PCM-300 Required Before PCM-900 or PCM-1600 Expansion
✓ PC-DM Module Enables Two-Wire EZ Decoder Operation up to 32 Total Stations
✓ Decoder Stations Require EZ-1 or EZ-LR Decoders
✓ 2 Year Hunter Warranty

Hunter HPC Controller Specifications
Hunter HPC Controller Installation Guide
Hunter HPC Controller Door Card
Hunter HPC Controller PCM-1600 Expansion Module Installation Guide
Hunter HPC Controller PC-DM Decoder Module Installation Guide
Hunter EZ Decoder System Brochure
Hunter HPC-FP Retrofit Upgrade Panel for Pro-C Specifications

More Information
Product Specifications
Product Videos
Hunter Controller HPC Wi-Fi Modular 4 Station Base (Max 23 Stations Conventional, 32 Stations Decoder)
HUNTER CONTROLLER HPC WI-FI MODULAR 4-32 STATIONS
Hunter Controller Pro-C Modular 4 Station Base (Max 23 Stations Conventional, 32 Stations Decoder)
Hunter Controller Pro-C Modular 4 Station Base (Max 23 Stations Conventional, 32 Stations Decoder) CNHPROC04
$350.97 /each
Hunter Controller HPC Wi-Fi Modular 4 Station Base (Max 23 Stations Conventional, 32 Stations Decoder)
Hunter Controller HPC Wi-Fi Modular 4 Station Base (Max 23 Stations Conventional, 32 Stations Decoder) CNHPROCHW
$460.41 /each
Hunter Pro-C / HPC 3 Station Expansion Module (PCM-300)
Hunter Pro-C / HPC 3 Station Expansion Module (PCM-300) CNHPROC03X
$88.84 /each
Hunter Pro-C / HPC 9 Station Expansion Module (PCM-900)
Hunter Pro-C / HPC 9 Station Expansion Module (PCM-900) CNHPROC09X
$358.39 /each
Hunter Pro-C / HPC 16 Station Expansion Module (PCM-1600)
Hunter Pro-C / HPC 16 Station Expansion Module (PCM-1600) CNHPROC16X
$427.94 /each
Hunter PC-DM Decoder Module for Pro-C / HPC (compatible with EZ-1 and EZ-LR)
Hunter PC-DM Decoder Module for Pro-C / HPC (compatible with EZ-1 and EZ-LR) CNHPCDM
$456.85 /each
Hunter EZ-1 Decoder Single Station (compatible with EZ-DM and PC-DM)
Hunter EZ-1 Decoder Single Station (compatible with EZ-DM and PC-DM) CNHEZ01
$159.25 /each
Hunter EZ-LR Long Range Decoder Single Station (compatible with EZ-DM and PC-DM)
Hunter EZ-LR Long Range Decoder Single Station (compatible with EZ-DM and PC-DM) CNHEZLR
$9,999 /each
Hunter HPC-FP Hydrawise Wi-Fi Upgrade Panel for Pro-C (PANEL ONLY)
Hunter HPC-FP Hydrawise Wi-Fi Upgrade Panel for Pro-C (PANEL ONLY) CNHPROCHWFP
$454.74 /each

The Hunter HPC Wi-Fi Modular 4 Station Base Controller is a flexible smart irrigation controller for residential and light commercial watering systems. Supplied as a 4 station base controller, it combines modular station expansion with built-in Hydrawise® control for app-based access, weather-based scheduling and remote irrigation management.

For conventional wired expansion, additional stations are added using compatible Hunter PCM expansion modules. The first expansion uses the PCM-300, which increases the controller to 7 stations. From there, one or two additional PCM-300 modules can be used for smaller expansions to 10 or 13 stations, while the PCM-900 expands the controller to 16 stations and the PCM-1600 expands it to 23 stations.

The HPC can also be upgraded for Hunter EZ Decoder System two-wire operation by installing the PC-DM module and using compatible EZ-1 or EZ-LR decoders. This allows the controller to support up to 32 total stations, with the first 4 stations conventionally wired and EZ decoder operation available from station 5 onward. A hybrid layout is also possible with PCM-300, allowing conventional stations 1–7 before decoder operation continues from station 8 onward.

With Hydrawise® smart irrigation control, touchscreen operation, flow monitoring options and built-in diagnostic features, the HPC is a practical choice for installations that need flexible expansion with modern Wi-Fi control.

2 Year Hunter Warranty

Hunter HPC Controller Specifications
Hunter HPC Controller Installation Guide
Hunter HPC Controller Door Card
Hunter HPC Controller PCM-1600 Expansion Module Installation Guide
Hunter HPC Controller PC-DM Decoder Module Installation Guide
Hunter HPC-FP Retrofit Upgrade Panel for Pro-C Specifications

Hunter EZ Decoder System Brochure
Hunter EZ Decoder System Specifications
Hunter EZ-1 Decoder Installation Guide
Hunter EZ-LR Decoder Installation Guide

✓ Controller Type & Station Outputs
Wi-Fi modular irrigation controller for residential and light commercial applications. Supplied as a 4 station base controller with a separate P/MV output for a master valve or pump start relay.

✓ Conventional Wiring Capacity
Expands to 23 conventional wired stations with compatible Hunter PCM station expansion modules.

✓ Module Selection / Installation Order
For conventional wired expansion, the PCM-300 must be installed first to add stations 5–7. From there, one or two additional PCM-300 modules can be used for smaller expansions to 10 or 13 stations, a PCM-900 module can be used to expand to 16 stations, or a PCM-1600 module can be used to expand to 23 stations.

✓ Decoder Wiring Capacity & Requirements
Supports up to 32 total stations with the compatible Hunter PC-DM Decoder Module. The first 4 stations remain conventionally wired, with EZ decoder operation available from stations 5–32. A hybrid layout is also possible with PCM-300, allowing conventional stations 1–7 before decoder operation continues from station 8 onward. Decoder stations require compatible Hunter EZ-1 or EZ-LR decoders. Decoders are sold separately.

✓ Installation Type
Plastic indoor/outdoor wall-mount controller with built-in Hydrawise® Wi-Fi control.

✓ Programming
6 independent irrigation programs with 6 start times per program.

✓ Smart Control Features
Hydrawise® provides app-based remote access, weather-based scheduling, controller alerts and smart irrigation management.

✓ Sensor and Flow Compatibility
2 sensor inputs available for compatible Hunter Clik sensors and HC Flow Meter.

✓ Display and Operation
Full-colour touchscreen controller interface with local programming and Wi-Fi setup.

✓ Diagnostic and Advanced Features
Includes built-in milliamp sensor for wire fault detection and alerts, Cycle and Soak, seasonal adjustment and advanced Hydrawise® scheduling features.

✓ Program Memory and Backup
Non-volatile memory retains programmed irrigation data during power outages.

✓ Electrical Output
24VAC transformer output, 1A. Station output 24VAC, 0.56A per station. P/MV output 24VAC, 0.28A.

✓ Enclosure, Certifications and Dimensions
Outdoor cabinet rated IP44. RCM approved. Approximately 229mm high x 254mm wide x 114mm deep.

✓ Warranty
2 Year Hunter Warranty.
