Filter Raindrip Super Plastic Body With 130 Disc (Red) 50mm BSPM
Filter Raindrip Super Plastic Body With 130 Disc (Red) 50mm BSPM

RAINDRIP PLASTIC IRRIGATION DISC FILTER 50MM SUPER 120 MESH / 130 MICRON

Raindrip 50mm Super plastic irrigation disc filter is a higher-capacity disc filter for irrigation systems. It uses a red 120 mesh / 130 micron disc element and has a larger Super body than the Medium 50mm model.

✓ Super Plastic Irrigation Disc Filter
✓ 50mm BSP Male Connections
✓ Red 120 Mesh / 130 Micron Disc
✓ 1000 kPa Pressure Rating
✓ 30m³/h Maximum Flow
✓ 1200cm² Filter Surface Area
✓ Stainless Steel Quick Release Clamp

Raindrip Plastic Disc Filter Specifications

More Information
Product Specifications
Filter Raindrip Super Plastic Body With 130 Disc (Red) 50mm BSPM
RAINDRIP PLASTIC IRRIGATION DISC FILTER 50MM SUPER 120 MESH / 130 MICRON
Filter Raindrip Small Plastic Body With 130 Disc (Red) 20mm BSPM
Filter Raindrip Small Plastic Body With 130 Disc (Red) 20mm BSPM FRPD20130
$25.75 /each
Filter Raindrip Small Plastic Body With 130 Disc (Red) 25mm BSPM
Filter Raindrip Small Plastic Body With 130 Disc (Red) 25mm BSPM FRPD25130
$25.75 /each
Filter Raindrip Medium Plastic Body With 130 Disc (Red) 40mm BSPM
Filter Raindrip Medium Plastic Body With 130 Disc (Red) 40mm BSPM FRPD40130
$119.93 /each
Filter Raindrip Medium Plastic Body With 130 Disc (Red) 50mm BSPM
Filter Raindrip Medium Plastic Body With 130 Disc (Red) 50mm BSPM FRPD50130
$161.14 /each
Filter Raindrip Super Plastic Body With 130 Disc (Red) 50mm BSPM
Filter Raindrip Super Plastic Body With 130 Disc (Red) 50mm BSPM FRSPD50130
$290.53 /each
Filter Raindrip Super Plastic Body With 130 Disc (Red) 80mm BSPM
Filter Raindrip Super Plastic Body With 130 Disc (Red) 80mm BSPM FRSPD80130
$398.97 /each

Raindrip 50mm Super plastic irrigation disc filter is a higher-capacity irrigation filter used to filter suspended particles from irrigation water and help protect downstream valves, sprinklers, dripline and irrigation components. It uses a red 120 mesh / 130 micron disc element in a Super plastic body with 50mm BSP male threaded connections.

This filter has a 1000 kPa pressure rating, 30m³/h maximum flow and 1200cm² filter surface area. The Super body includes a stainless steel quick release clamp for easier access during cleaning and maintenance. This is the Super 50mm model, not the Medium 50mm disc filter.

Raindrip Plastic Disc Filter Specifications

✓ Product Type & Model
Raindrip Super plastic irrigation disc filter, part number S50D130.

✓ Application
Used to filter suspended particles from irrigation water and help protect valves, sprinklers, dripline and irrigation components.

✓ Filter Type
Disc filter.

✓ Mesh / Micron Rating
Red 120 mesh / 130 micron disc element.

✓ Connection Size
50mm BSP male threaded connections.

✓ Body Style
Super plastic body.

✓ Pressure Rating
1000 kPa.

✓ Maximum Flow
30m³/h.

✓ Filter Surface Area
1200cm².

✓ Gauge Port
1/4" BSP pressure gauge mounting point.

✓ Drain Connection
3/4" BSP drain connection.

✓ Approximate Dimensions
595mm high x 324mm wide x 138mm upper body height.

✓ Materials
Polypropylene filter body, polypropylene disc element, EPDM O-ring, 304 stainless steel spring and 304 stainless steel quick release clamp.

✓ Installation
Install in the correct flow direction and allow access for cleaning and maintenance.

✓ Maintenance
Disc element should be inspected and cleaned as part of normal irrigation system maintenance. The quick release clamp assists access to the filter element.

✓ Compatibility Note
This is the Super 50mm disc filter. Confirm whether the installation requires the Medium 50mm or Super 50mm model before ordering.
