CABLE MULTICORE 2 CORE 1.0MM² IN OUTER SHEATH 100 METRE

Multicore 2 core 1.0mm² irrigation cable in outer sheath, supplied in a 100m roll for extra low voltage controller-to-solenoid valve wiring. Suitable for direct burial irrigation applications.

✓ 2 Core Irrigation Cable
✓ 1.0mm² Conductor Size
✓ 100m Roll Length
✓ Direct Burial Suitable
✓ 30V Extra Low Voltage Rated
✓ For Irrigation Controllers and Solenoid Valves

Multicore Irrigation Cable Specifications

More Information
Product Specifications
Cable Multicore (2 Core) 1.0 mm in Outer Sheath, 100 Metre
CABLE MULTICORE 2 CORE 1.0MM² IN OUTER SHEATH 100 METRE
Cable Multicore (2 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (2 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC02100-10
$144.63 /each
Cable Multicore (2 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (2 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC02500-10
$723.22 /each
Cable Multicore (3 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (3 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC03100-10
$192.88 /each
Cable Multicore (3 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (3 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC03500-10
$959.15 /each
Cable Multicore (5 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (5 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC05100-10
$309.70 /each
Cable Multicore (5 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (5 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC05500-10
$1,646.36 /each
Cable Multicore (7 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (7 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC07100-10
$443.84 /each
Cable Multicore (7 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (7 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC07500-10
$2,225.44 /each
Cable Multicore (9 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (9 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC09100-10
$557.90 /each
Cable Multicore (9 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (9 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC09500-10
$2,795.83 /each
Cable Multicore (13 Core) 1.0 mm in Outer Sheath, 100 Metre
Cable Multicore (13 Core) 1.0 mm in Outer Sheath, 100 Metre WLVC13100-10
$774.44 /each
Cable Multicore (13 Core) 1.0 mm in Outer Sheath, 500 Metre
Cable Multicore (13 Core) 1.0 mm in Outer Sheath, 500 Metre WLVC13500-10
$3,878.23 /each

Multicore 2 core 1.0mm² irrigation cable in outer sheath is extra low voltage direct burial cable used to connect irrigation controller outputs to solenoid valves. This 2 core cable is supplied in a 100 metre roll for irrigation valve wiring runs.

The two colour-coded cores can be used for simple controller-to-valve wiring, depending on the irrigation system design. Use suitable waterproof wire connectors for buried, valve box or exposed irrigation cable joins.

Multicore Irrigation Cable Specifications

✓ Product Type & Size
Multicore irrigation cable, 2 core x 1.0mm², supplied in a 100m roll.

✓ Application
Extra low voltage irrigation valve cable for connecting nominal 24V irrigation controller outputs to solenoid valves.

✓ Voltage Rating
30V rated cable.

✓ Cable Format
Flat 2 core cable in outer sheath.

✓ Installation
Suitable for direct burial irrigation applications.

✓ Conductor
Class 2 plain copper conductor to AS1125. 1.0mm² conductor size with 7/0.43 strand construction.

✓ Electrical Data
Maximum D.C. resistance at 20°C is 21.2mΩ/m.

✓ Core Insulation
PP UV stabilised colour-coded core insulation, nominal 0.45mm insulation thickness.

✓ Outer Sheath
PVC 5V90 UV stabilised blue sheath to AS/NZS 3808:2000 with nylon rip cord. Nominal sheath thickness is 0.6mm.

✓ Nominal Outside Diameter
6.4mm x 3.6mm nominal outside diameter.

✓ Core Colours
Black and white.

✓ Joining Note
Use suitable waterproof wire connectors for buried, valve box or exposed irrigation cable joins. Poor cable joints can cause corrosion, voltage loss and premature system failure.

✓ Safety Note
Extra low voltage irrigation cable only. Not suitable for mains power connection.
