WATER METER NETAFIM WOLTMAN TURBO 50MM FLANGED

Netafim Woltman Turbo 50mm flanged water meter is a mechanical bulk water meter for agricultural, industrial and water supply network applications.

✓ 50mm Mechanical Water Meter
✓ Table D Flanged Connection
✓ AS4747 & NMI 10 Pattern Approved
✓ Cast Iron Polyester-Coated Body
✓ 16 Bar Standard Working Pressure
✓ Check Installation Requirements Before Ordering

Woltman Water Meter Specifications

More Information
Product Specifications
Water Meter Netafim Woltman Turbo 50mm Flanged
WATER METER NETAFIM WOLTMAN TURBO 50MM FLANGED
Water Meter Netafim Woltman Turbo 50mm Flanged
Water Meter Netafim Woltman Turbo 50mm Flanged WMNWT050
$1,095.71 /each

Water Meter Netafim Woltman Turbo 50mm flanged is a mechanical bulk water meter used for agricultural, industrial and water supply network applications. The Woltman Silver Turbo WSTsb design is suited to a wide measuring range, making it suitable for installations where both low-flow and high-flow performance need to be considered.

This 50mm model has a Table D flanged connection, cast iron polyester-coated body and AS4747 / NMI 10 Pattern Approval. It is suitable for approved water metering applications, including installations where Murray Darling Basin Pattern Approval requirements need to be considered. Confirm flow range, flange compatibility and installation requirements before ordering.

Woltman Water Meter Specifications

✓ Product Type & Size
Netafim Woltman Silver Turbo WSTsb mechanical bulk water meter, 50mm / 2".

✓ Connection
Table D flanged connection.

✓ Application
Suitable for water supply networks, agricultural applications and industrial water metering.

✓ Approval
AS4747 and NMI 10 Pattern Approved.

✓ Body
Cast iron, polyester-coated body.

✓ Maximum Working Pressure
16 bar standard. 25 bar available upon request.

✓ Maximum Liquid Temperature
60°C.

✓ Flow Performance
Q1 minimum flow rate: 0.63 m³/h.
Q2 transitional flow rate: 1.01 m³/h.
Q3 nominal flow rate: 63 m³/h.
Q4 maximum flow rate: 78.75 m³/h.
Starting flow: 0.15 m³/h.

✓ Accuracy
Accuracy between Q4 and Q2: ±2%.
Accuracy between Q2 and Q1: ±5%.

✓ Register & Readability
Maximum register capacity: 10⁶ m³.
Smallest readable unit: 0.5 litre.
R value: 100.

✓ Dimensions
Length without couplings: 200mm.
Width: 165mm.
Height: 214mm.
Lower height: 70mm.
Weight: 12kg.

✓ Installation Note
The meter must remain full of water during operation. Flush the pipeline thoroughly before installation. For 2"–6" meters, install with 5D upstream and 2D downstream straight pipe sections. For NMI M10 installations, refer to the approval certificate.
