Concrete Septic Tank with Base Cast In w 1500 x h 1500 mm 2120 L 1840kg
Concrete Septic Tank with Base Cast In w 1500 x h 1500 mm 2120 L 1840kg

CONCRETE SEPTIC TANK WITH BASE CAST IN 1500MM ID X 1530MM DEEP 1970L 1840KG

Concrete septic tank with cast-in base, 1500mm internal diameter x 1530mm deep, with 1970L capacity. Suitable for approved onsite wastewater systems where site and approval requirements have been checked.

✓ 1500mm Internal Diameter
✓ 1530mm Deep with Base Cast In
✓ 1970L Capacity
✓ 75mm Wall Thickness
✓ Approximate Weight 1840kg
✓ Approved to AS/NZS 1546

Concrete Septic Tank Specifications

More Information
Product Specifications
Concrete Septic Tank with Base Cast In w 1500 x h 1500 mm 2120 L 1840kg
CONCRETE SEPTIC TANK WITH BASE CAST IN 1500MM ID X 1530MM DEEP 1970L 1840KG
Concrete Septic Tank with Base Cast In w 1200 x h 1500 mm 1697 L 1400kg
Concrete Septic Tank with Base Cast In w 1200 x h 1500 mm 1697 L 1400kg NCST1200WB
$570.90 /each
Concrete Septic Tank with Base Cast In w 1500 x h 1500 mm 2120 L 1840kg
Concrete Septic Tank with Base Cast In w 1500 x h 1500 mm 2120 L 1840kg NCST1500WB
$685.30 /each
Concrete Septic Tank (2 x tanks) 1500 ID 1200 ID w/Standard Cover Split Lid, w/Bases Cast In 3860kg
Concrete Septic Tank (2 x tanks) 1500 ID 1200 ID w/Standard Cover Split Lid, w/Bases Cast In 3860kg NCST2SWB
$1,584 /each
Concrete Septic Tank (2 x tanks) 1500 ID 1200 ID w/Traffic Cover Split Lid, w/Bases Cast In 3860kg
Concrete Septic Tank (2 x tanks) 1500 ID 1200 ID w/Traffic Cover Split Lid, w/Bases Cast In 3860kg NCST2TWB
$1,812.25 /each

Concrete septic tank with cast-in base, 1500mm internal diameter x 1530mm deep, is used for onsite wastewater systems where an approved precast concrete septic tank is required. It is suitable for installations requiring a 1970L tank capacity, provided the system design, approval requirements and site conditions are suitable.

This concrete septic tank has 75mm wall thickness, a 100mm inlet height of 1240mm from the bottom and a 100mm outlet height of 1160mm from the bottom. The approximate tank weight is 1840kg. Confirm wastewater system requirements, local approvals, site access, lifting and unloading arrangements before ordering.

Concrete Septic Tank Specifications

✓ Product Type & Size
Concrete septic tank with cast-in base, 1500mm internal diameter x 1530mm deep.

✓ Material
Concrete.

✓ Capacity
1970L capacity.

✓ Wall Thickness
75mm wall thickness.

✓ Inlet Height
100mm diameter inlet height is 1240mm from the bottom.

✓ Outlet Height
100mm diameter outlet height is 1160mm from the bottom.

✓ Approval
Approved to Australian Standard AS/NZS 1546. Complies with Department of Health requirements under the Code of Practice for Product Approval of Onsite Wastewater Systems.

✓ Approval Number
Approval # F-AA-31116.

✓ Approximate Weight
Approximately 1840kg. Weights and measurements are a guide only and some variation may occur.

✓ Applications
Suitable for onsite wastewater systems where the tank size, capacity, approval and installation method suit the site requirements.

✓ Installation Note
Confirm wastewater system design, tank sizing, local approval requirements, site access and unloading arrangements before ordering. Suitable lifting equipment is required.
