Seaflo Submersible Inline Pump 200GPH 12V
Seaflo Submersible Inline Pump 200GPH 12V

SEAFLO 200GPH 12V INLINE PUMP

The Seaflo 200GPH 12V inline pump transfers clean water from tanks and containers in a compact format. It can operate submerged or inline with a flooded inlet, giving flexibility in how the water supply is arranged. The 1m lead suits connections close to the pump. The pump is not self-priming, so water must reach the inlet before operation.

✓ Fluid: Clean water
✓ Maximum flow: 11.7L/min
✓ Maximum head: 5m
✓ Hose connection: 1/2"
✓ Supply: 12V DC
✓ Nominal capacity: 200GPH

Seaflo 200GPH Inline and Submersible Pump Product Information

More Information
Product Specifications
Seaflo Submersible Inline Pump 200GPH 12V
SEAFLO 200GPH 12V INLINE PUMP
Seaflo Submersible Inline Pump 200GPH 12V
Seaflo Submersible Inline Pump 200GPH 12V PUMP-SFSP1-G200-03
$55.62 /each

Transfer clean water from a tank or container with this 12V Seaflo pump, rated for up to 11.7L/min and a maximum head of 5m. Its 1/2" hose connection carries the discharge, and it is supplied with a 1m lead.

The pump can operate submerged or inline with a flooded inlet. It is not self-priming: water must reach the inlet before the motor starts. Keep the water supply available throughout operation.

Flow falls as lift and hose resistance increase. Maximum flow and maximum head are separate limits; the linked sheet gives flow at the listed discharge heads.

Seaflo 200GPH Inline and Submersible Pump Product Information

✓ Product Type & Application
Inline or submerged pump for transferring clean water from tanks and containers.
Fluid: Clean water
Model: SFSP1-G200-03

✓ Capacity & Performance
Maximum flow: 11.7L/min
Maximum head: 5m
Nominal capacity: 200GPH
Maximum flow and maximum head are separate limits; flow decreases as lift and hose resistance increase.

✓ Flow at Discharge Head
0m head: 707L/h
1m head: 575L/h
2m head: 389L/h
3m head: 317L/h
4m head: 174L/h
5m head: 0L/h

✓ Connections & Compatibility
Hose connection: 1/2"

✓ Electrical & Leads
Power supply: 12V DC
Lead length: 1m

✓ Installation & Use
Can operate submerged or inline with a flooded inlet.
Not self-priming: water must reach the inlet before starting.
Keep water available at the inlet during operation.
