SEAFLO 2000GPH bilge pump, representative 01-series housing photo
SEAFLO 2000GPH bilge pump, representative 01-series housing photo
SEAFLO 2000GPH bilge pump, representative 01-series housing photo

SEAFLO 2000GPH 24V BILGE PUMP

The Seaflo 2000GPH bilge pump removes accumulated water from boat bilges using a 24V supply. Separate switching lets it work with a manual control or an external float switch, so the control arrangement can suit the boat installation. The removable inlet strainer gives access to clear debris from the pump inlet.

✓ Maximum flow: 121L/min
✓ Maximum head: 8m
✓ Hose outlet: 1 1/8"
✓ Supply: 24V DC
✓ Control: Non-automatic
✓ Nominal capacity: 2000GPH

Seaflo Non-Automatic Bilge Pumps Specifications

More Information
Product Specifications
SEAFLO 2000GPH bilge pump, representative 01-series housing photo
SEAFLO 2000GPH 24V BILGE PUMP
SEAFLO 2000GPH bilge pump, representative 01-series housing photo
Seaflo Manual Bilge Pump 2000GPH 12V PUMP-SFBP1-G2000-01
$120.90 /each
SEAFLO 2000GPH bilge pump, representative 01-series housing photo
Seaflo Manual Bilge Pump 2000GPH 24V PUMP-SFBP2-G2000-01
$120.90 /each

The Seaflo 2000GPH bilge pump removes accumulated water from boat bilges, with a maximum flow of 121L/min and maximum head of 8m. The discharge connects to 1 1/8" hose. Available with a 24V DC supply.

Use a manual switch for direct control, or connect a separate float switch for automatic operation as the bilge water level changes. The removable inlet strainer provides access to clear debris.

Maximum flow applies at low discharge head. Flow reduces as lift and hose resistance increase, reaching zero at maximum head.

Seaflo Non-Automatic Bilge Pumps Specifications

✓ Product Type & Application
Non-automatic submersible bilge pump for removing accumulated water from boats.
Model: SFBP2-G2000-01

✓ Capacity & Performance
Maximum flow: 121L/min
Maximum head: 8m
Nominal capacity: 2000GPH
Maximum flow and maximum head are separate limits; flow decreases as lift and hose resistance increase.

✓ Connections & Compatibility
Hose outlet: 1 1/8"

✓ Electrical & Leads
Power supply: 24V DC

✓ Operation & Control
Control: Non-automatic

✓ Construction & Features
Removable inlet strainer for access when clearing debris.

✓ Installation & Use
Requires manual switching or a separate float switch for automatic operation.
