The Seaflo AG 35 is a 12V DC diaphragm pump for agricultural spraying and compatible liquid transfer. Its built-in pressure switch starts the pump as system pressure falls and stops it when shutoff pressure is reached.
The pump is supplied with two-pin leads. Use Seaflo Quick Attach fittings matched to the pump ports to connect the inlet and outlet hoses.
Maximum open flow is 7LPM. The pressure switch stops the pump at 120psi (about 830kPa). These are separate limits: flow decreases as pressure rises, and the pump does not deliver its maximum flow at shutoff pressure.
Inlet: 16mm (5/8") Seaflo Quick Attach port.
Outlet: 16mm (5/8") Seaflo Quick Attach port.
Viton valves and a Santoprene diaphragm suit compatible agricultural liquids. Check the liquid, concentration and temperature against all wetted materials before pumping chemicals. The valve material does not establish compatibility with every chemical or approval for drinking-water and food applications.
The three-chamber diaphragm design provides automatic demand operation for moderate-flow, higher-pressure spraying and transfer systems. Keep the supplied pressure setting; refer any setting change to Seaflo.
The pump is self-priming with a suction lift up to 1.8m. Usable lift depends on the inlet hose, air leaks and the liquid being pumped. Dry-running capability does not provide automatic shutdown when a tank is empty; switch off when the liquid supply runs out.
Continuous duty; follow the operating limits in the supplied instructions. Use liquid at temperatures up to 60°C, subject to chemical compatibility.
Fit a suitable inlet strainer and flexible reinforced hose, keeping suction joints airtight. Secure the pump using its rubber mounting feet without overtightening them, and protect the motor and electrical connections from water.
The pump requires a 12V DC supply. Maximum current is 12A.
Two-year warranty, subject to its terms.
