OASE AQUAMAX ECO CLASSIC POND PUMPS

OASE AquaMax Eco Classic pumps carry pond water and debris to filters, waterfalls and watercourses. The 3500 E, 5500 and 8500 deliver maximum flows of 3,500L/h, 5,300L/h and 8,300L/h. A large strainer passes debris up to 8mm, and the supplied stepped hose adaptor accepts 25mm, 32mm or 38mm hose.

✓ Maximum Flow: 3,500L/h to 8,300L/h by Model
✓ Maximum Head: 2.6m to 3.2m by Model
✓ Handles Debris Up to 8mm
✓ 25mm, 32mm & 38mm Hose Adaptor Included

OASE AquaMax Eco Classic Instructions

Pond Pump Oase Aquamax Eco Classic 8500

OASE AquaMax Eco Classic pumps carry pond water and debris to filters, waterfalls and watercourses. The 3500 E, 5500 and 8500 deliver maximum flows of 3,500L/h, 5,300L/h and 8,300L/h. A large strainer passes debris up to 8mm, and the supplied stepped hose adaptor accepts 25mm, 32mm or 38mm hose.

The pump moves debris to a separate filter rather than removing it from the pond water itself. Environmental Function Control responds to blockage and dry running. The mechanical hose connection uses a swivelling adaptor to help route the hose without a sharp bend.

Install submerged or externally with the pump below the source water level and a continuously flooded inlet. It does not prime a dry suction pipe or lift water into the inlet. The motor is not electronically speed-adjustable. Maximum flow and maximum head are separate limits; actual delivery depends on lift and pipe losses.

Three-year manufacturer warranty. Register with OASE during the standard three-year warranty period, with proof of purchase, for two additional years (five years total), subject to OASE warranty terms. Register the OASE extended warranty.

OASE AquaMax Eco Classic Instructions

✓ Application
Moving pond water and debris to external filters, waterfalls and watercourses.

✓ Warranty
Three-year manufacturer warranty. Register with OASE during the standard three-year warranty period, with proof of purchase, for two additional years (five years total), subject to OASE warranty terms.

✓ Model Specifications
AquaMax Eco Classic 8500
Maximum flow: 8,300L/h.
Maximum head: 3.2m.
1 1/2" threaded inlet and outlet (G1 1/2).

AquaMax Eco Classic 3500 E
Maximum flow: 3,500L/h.
Maximum head: 2.6m.
1" threaded inlet and outlet (G1).

AquaMax Eco Classic 5500
Maximum flow: 5,300L/h.
Maximum head: 2.8m.
1 1/2" threaded inlet and outlet (G1 1/2).

✓ Supplied Hose Adaptor
Stepped adaptor accepts 25mm, 32mm or 38mm hose.

✓ Debris & Protection
Debris up to 8mm. Environmental Function Control for blockage and dry-running protection. Not electronically speed-adjustable.

✓ Construction
Large strainer housing with swivelling hose adaptor; 810cm2 intake strainer area.

✓ Water Suitability
Freshwater pond use.

✓ Installation
Submerged or external flooded-inlet installation below source water level. Not self-priming.

✓ Power Supply & Cable
Supply: 220-240V AC, 50Hz.
Power cable: 10m.

AquaMax Eco Classic 8500
Power: 80W.

AquaMax Eco Classic 3500 E
Power: 35W.

AquaMax Eco Classic 5500
Power: 60W.
