FLOAT VALVE PHILMAC OPTIPHIL 25MM ABOVE WATER

The Philmac OptiPHIL 25mm Above Water combines high-flow tank and trough filling with a compact float design. Its own operating float and connection adaptors are included. The valve works above the water and must be mounted vertically so the float and pilot mechanism can operate correctly.

✓ Valve size: 25mm (1")
✓ Working pressure: 10-1200kPa
✓ Flow: 847 L/min at 1200kPa
✓ Minimum required flow: 1 L/min
✓ Above-water installation; mount vertically within +/-5 degrees
✓ Float and connection adaptors included

Philmac OptiPHIL Brochure
Philmac OptiPHIL Specifications & Above-Water Installation
Philmac Float Valve Range Brochure

More Information
Product Specifications
Product Videos
Float Valve Philmac OptiPHIL 25mm Above Water
FLOAT VALVE PHILMAC OPTIPHIL 25MM ABOVE WATER
Float Valve Philmac OptiPHIL 25mm Above Water
Float Valve Philmac OptiPHIL 25mm Above Water TFPHOP25
$73.13 /each

The Philmac OptiPHIL 25mm Above Water combines high-flow tank and trough filling with a compact float design. Its own operating float and connection adaptors are included. The valve works above the water and must be mounted vertically so the float and pilot mechanism can operate correctly.

This is model 93600110. It operates from 10kPa to 1200kPa and requires at least 1 L/min flow. Mount vertically within +/-5 degrees and leave clearance for the float movement.

Philmac OptiPHIL Brochure
Philmac OptiPHIL Specifications & Above-Water Installation
Philmac Float Valve Range Brochure

✓ Level Control & Float Requirements
Single shut-off level; above-water model with its own float arrangement.
Supplied components: Float and adaptors.

✓ Connections & Mounting
Connection size: 25mm (1").
Orientation: Vertical, within +/-5 degrees.

✓ Pressure & Temperature
Working pressure: 10-1200kPa.
Working temperature: 1-60°C.

✓ Flow Performance
Minimum flow: 1 L/min.
Flow rate: 847 L/min at 1200kPa; installed flow depends on the supply.

✓ Compatibility & Use
Model: 93600110 above-water valve.
