BRASS CAPILLARY WALL PLATE ELBOWS COPPER X FEMALE BSP

Brass capillary wall plate elbows connect copper pipe to a fixed female BSP threaded outlet at 90°. Suitable for wall-mounted taps, valves, hose cocks, mixer connections and irrigation outlet points.

✓ For Copper Pipe
✓ Capillary x Female BSP Connection
✓ Lugged Wall Plate Elbow
✓ DR Lead Free Brass Body
✓ WaterMark Lead Free Approved
✓ 1600kPa Maximum Pressure Rating

Brass Capillary Wall Plate Elbow Copper x Female BSP Specifications

More Information
Product Specifications
Brass capillary wall plate elbow with female threaded outlet and two fixing holes.
BRASS CAPILLARY WALL PLATE ELBOWS COPPER X FEMALE BSP
Brass capillary wall plate elbow with female threaded outlet and two fixing holes.
Brass Elbow Capillary Wall Plate Cap FI 20mm OD x 1/2" BSP ** limited stock ** B08CWC2015
$4.64 /each

Brass capillary wall plate elbows are used to connect copper pipe to a fixed female BSP threaded outlet at 90°. They are commonly used for wall-mounted plumbing outlets where copper pipe needs to finish at a secure threaded connection for a tap, valve, mixer connection, hose cock, irrigation outlet or other compatible male BSP fitting.

Made from DR lead free brass, these lugged wall plate elbows have a capillary socket for copper pipe and a female BSP internal thread for the outlet connection. The lugged base allows the fitting to be fixed securely to a wall, noggin, backing board or mounting surface before the connected tap or fitting is installed.

Brass Capillary Wall Plate Elbow Copper x Female BSP Specifications

✓ Product Type & Size
Brass capillary wall plate elbow for copper pipe.

✓ Connection Type
Capillary copper pipe socket x Female BSP threaded outlet.

✓ Material
DR lead free brass body.

✓ Pipe Compatibility
Designed for use with correctly prepared copper pipe in the matching outside diameter.

✓ Pressure Rating
Maximum pressure rating 1600kPa, subject to correct installation, compatible pipe, soldering method and application conditions.

✓ Temperature Range
Working temperature range 1°C to 99°C.

✓ Standards & Approvals
WaterMark Lead Free approved. Tested and certified to AS 3688.

✓ Applications
Suitable for fixed wall outlet points, tap connections, hose cock outlets, valve connections, mixer connections, irrigation take-offs and general plumbing installations using copper pipe.

✓ Installation
Prepare the copper pipe correctly for the capillary connection and solder the fitting using suitable plumbing practice. Fix the lugged wall plate securely to the mounting surface before connecting a compatible male BSP threaded tap, valve or fitting into the female BSP outlet.
